You can detect defects in real time before they disturb the process

Web Inspection - Continuous Detection of Defects

   •  Seamless integration to Procemex web monitoring system.
   •  TAPPI Dirt Count Capable
   •  Faster Start-ups with Higher Level Classification
   •  Reduction in Waste with Roll Quality Analysis
   •  Identification of Root Cause
   •  Integration to Procemex Web Monitoring
   •  Application Specific Geometries for Detection
   •  Simple User Interface for Immediate Use

To achieve detection of relevant defects digital Procemex Flex cameras are installed to a multiple camera beam or beams, when detection is required at multiple locations or on both sides of the sheet. This specially constructed carbon fiber beam absorbs machine vibration and is sturdy enough for the widest machines in the world. Sheet widths well up to 12 meters can easily be reached.
Some defects may be in different layers inside the web which requires different illumination for detection. Procemex Flex camera controls up to 3 separate strobe light sources simultaneously. The flashing of each light source takes place in individual sequences at the same point of the web, so the actual point is being inspected 3 times, each under different light conditions. The results of these three images are combined for reliable conclusions on the defect type and location (bottom, middle, top layer). This type of triple defect inspection requires 3 times higher data processing capacity over a single light source use. >> Learn more
