For enhanced personnel safety, controlling access to gated areas is crucial. The Pilz PSENmgate safety gate system provides a compact yet robust solution, measuring just 40 x 65 x 238 mm—over 40% smaller than its predecessor, the PSENsgate—while improving key specifications.
The all-metal PSENmgate achieves PLe, Category 4 (EN ISO 13849-1), boasts a 7500 N holding force, and is IP65 rated, making it suitable for demanding applications. Flexible, RFID-coded actuators tolerate door misalignment. Accessories, including door handles with integrated escape release and lockout points, further enhance the solution. The PSENmgate supports front, side, and back actuator entry, accommodating both swing and sliding gates.
Available with standard or LED illuminated buttons and an optional emergency stop, the PSENmgate also features quick-connect M12 or M23 cable reducing your installation time.
Key Benefits:
Compact Size: 40 x 65 x 238 mm
High Safety Rating: Achieving PLe, Category 4 (EN ISO 13849-1) ensures a high level of safety and compliance with relevant standards.
Robust Construction: all-metal design with IP65 protection and 10g of shock resistance.
High Holding Force: 7500 N holding force ensures secure locking even in demanding applications.
Tolerance of Misalignment: Flexible, RFID-coded actuators accommodate door misalignment overtime.
Fast Installation: Quick-connect M12 or M23 options simplify and speed up installation.
Contact your local Pilz representative to discuss your Safety locking device needs!
